Post by Tablab22 on Thu Oct 08, 2015 8:01 pm

Hi Joel, I would like to order the epoxy and tape for construction of my canoe from you.  My plans don't give me a material list for those items so I was hoping you could help.  I am attaching a photo of the mid section so you can see how many joins I will have.  Each side piece has three tape joins as well. OK, I need help. I don't know how to post a photo. The canoe has nine stitch joins long ways and is 17' long. I plan to call you Friday to place my order.
Thanks

Tablab22

Posts : 8
Join date : 2015-10-05

View user profile

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Admin - Shine on Fri Oct 09, 2015 8:50 am

Tablab22 wrote:Hi Joel, I would like to order the epoxy and tape for construction of my canoe from you.  My plans don't give me a material list for those items so I was hoping you could help.  I am attaching a photo of the mid section so you can see how many joins I will have.  Each side piece has three tape joins as well.  OK, I need help. I don't know how to post a photo.  The canoe has nine stitch joins long ways and is 17' long.  I plan to call you Friday to place my order.
Thanks

I can certainly help. You can email pictures to joel@gulfstreamcomposites.com phone is 772.633.7923
Admin - Shine
Admin - Shine
Admin

Posts : 488
Join date : 2015-03-31

View user profile http://gulfstreamcomposites.forumotion.com

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Admin - Shine on Sat Oct 10, 2015 3:19 pm

sorry I missed your call yesterday afternoon. I will give you a call first thing monday (or you can call me if thats better) and we will get it rolling

Joel
Admin - Shine
Admin - Shine
Admin

Posts : 488
Join date : 2015-03-31

View user profile http://gulfstreamcomposites.forumotion.com

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Tablab22 on Sun Oct 11, 2015 10:27 pm

Thanks Joel, I'll call tomorrow.  I picked up some 1/2" MDF and laid out the stations and marked the pieces out.  I am using the MDF as templates for routering the pieces out of marine ply.  The plan calls for four pieces of each part. I figure this way they will all be exactly the same.  It took me two hours to layout, cut and sand the edges of my templates.

Tablab22

Posts : 8
Join date : 2015-10-05

View user profile

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Admin - Shine on Mon Oct 12, 2015 7:32 am

I am using the MDF as templates for routering the pieces out of marine ply.  The plan calls for four pieces of each part. I figure this way they will all be exactly the same.  It took me two hours to layout, cut and sand the edges of my templates.

thats a good idea and worth the time.

17' Stitch & Glue Canoe Img_0010

17' Stitch & Glue Canoe Img_0011

17' Stitch & Glue Canoe Img_0012

17' Stitch & Glue Canoe Img_0013
Admin - Shine
Admin - Shine
Admin

Posts : 488
Join date : 2015-03-31

View user profile http://gulfstreamcomposites.forumotion.com

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Tablab22 on Wed Oct 14, 2015 6:16 pm

Joel I received my order yesterday. Thanks very quick shipping.

Tablab22

Posts : 8
Join date : 2015-10-05

View user profile

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Tablab22 on Sun Oct 25, 2015 5:34 pm

I spent four hours on Saturday cutting out all the pieces and routed them using my templates. I then epoxied the four pieces per length together. The epoxy was very easy to use. Hindsight, I wish I had a small amount of medium hardener, the slow hardener took six hours before the pieces could be flipped for me to do the other side. Sunday morning I cut the mold stations and assembled a jig to stitch the canoe. After a couple of hours the canoe was stitched. Next week ends adventure will be filleting and taping. It is very satisfying to see it take shape. I can only imagine the thrill of completing a skiff.

Tablab22

Posts : 8
Join date : 2015-10-05

View user profile

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Admin - Shine on Mon Oct 26, 2015 9:18 am

Tablab22 wrote:I spent four hours on Saturday cutting out all the pieces and routed them using my templates.  I then epoxied the four pieces per length together.  The epoxy was very easy to use.  Hindsight, I wish I had a small amount of medium hardener, the slow hardener took six hours before the pieces could be flipped for me to do the other side.  Sunday morning I cut the mold stations and assembled a jig to stitch the canoe.  After a couple of hours the canoe was stitched. Next week ends adventure will be filleting and taping.  It is very satisfying to see it take shape.  I can only imagine the thrill of completing a skiff.

That's great!  I got the pictures and will post them for you.  Is a very rewarding step to see the hull shape "appear"  Very Happy

Question: What wood are you using? Looks like fir, have any issue twisting it up at the bow?


Last edited by Admin - Shine on Mon Oct 26, 2015 9:27 am; edited 1 time in total
Admin - Shine
Admin - Shine
Admin

Posts : 488
Join date : 2015-03-31

View user profile http://gulfstreamcomposites.forumotion.com

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Admin - Shine on Mon Oct 26, 2015 9:26 am

here is a gallery of images....

https://goo.gl/photos/3tUusKsSbynqX28S7

here are a few of the pictures....

17' Stitch & Glue Canoe Img_0014

17' Stitch & Glue Canoe Img_0015

17' Stitch & Glue Canoe Img_0110

17' Stitch & Glue Canoe Img_0111

17' Stitch & Glue Canoe Img_0112


Admin - Shine
Admin - Shine
Admin

Posts : 488
Join date : 2015-03-31

View user profile http://gulfstreamcomposites.forumotion.com

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Tablab22 on Mon Oct 26, 2015 4:24 pm

Since this project is to familiarize myself with the products and methods of DIY boat building, I am using Marine grade Fir ply. I figured I would be painting it. I didn't have any problems getting the ply to conform to the jig.

Tablab22

Posts : 8
Join date : 2015-10-05

View user profile

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Admin - Shine on Tue Oct 27, 2015 2:50 pm

Tablab22 wrote:Since this project is to familiarize myself with the products and methods of DIY boat building, I am using Marine grade Fir ply.  I figured I would be painting it.  I didn't have any problems getting the ply to conform to the jig.

Since your going to glass the whole outside, it will keep print through in check. I asked the question more out of curiosity in regards to the twisting.
Admin - Shine
Admin - Shine
Admin

Posts : 488
Join date : 2015-03-31

View user profile http://gulfstreamcomposites.forumotion.com

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Admin - Shine on Tue Nov 24, 2015 12:42 pm

So, how is the canoe coming along?
Admin - Shine
Admin - Shine
Admin

Posts : 488
Join date : 2015-03-31

View user profile http://gulfstreamcomposites.forumotion.com

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Tablab22 on Tue Nov 24, 2015 8:39 pm

Hi Joel, I've been slacking but have made a little progress. The stitches are removed and all the panels are epoxied together. The canoe is ready for the outside glass. I hope to do that this weekend weather permitting. I have been kicked out of my buddies cabinet shop. He got a large job and needed the room. Its amazing the difference working in a shop makes. My home has a one car garage and not very roomy to work in. I've sent you some pics of the progress to post for me.
Thanks and Happy Thanksgiving.

Tablab22

Posts : 8
Join date : 2015-10-05

View user profile

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Admin - Shine on Wed Nov 25, 2015 8:20 am

Tim, its looking nice! Happy Thanksgiving to you too.


17' Stitch & Glue Canoe 0nVarxyupiFODmT7R2Gu_r8I1LhQyeVcM-XVTqESBz_XVAO4GExcUQ1PhipjJ8khjqC99gRlWO_XJ7cJnFxIelPyeEVPl_ZQGZI-4mlEjmbqk8sNdGfWbTvhlmBq1__hFoqhU37XE_lTmZhPnZtXywtTna1fwkZWXJJej0g9zye5hCymRdK9QfbrBde3Y6a6eN6FpY6odmhPe6X5bWwr6I0irfq1GCjuL4ldrzgioDpdgELHKJtqlblsRKlR50Luu320c_sKlmWEAXtS47pLEA-IKjme3WncYV1vBjYzF8btmpdw12e4vcRrKja4vRL8moYk6ZSlBGFX5WSczV0dz4dckog0XQ6m21cCqXMFiKvrzA1C8sXu5kf3zfvvAUgDrhPBxvpsdgjROt9J9V5p47InIKELBmuX8q4FqJ1Fa9BTTL7xgbSw9xvTdr4DHJ7W-Ly5pCl2xeMNN5UylLT9p5UIZZCjixEnHSXv4pbPpHXHK2_2UfPPuadPz4RMZVz4NH1Bk8T79CISEk_haksOFOsKZ5kwfSLZJzSwWWweMv4=w549-h732-no

17' Stitch & Glue Canoe YvHzorXbHYXT-FQ-2oBXaUc79OPIJf1O4O3FC1y6eE0AZDhyzwnE6rdU2GvQ7dHLIPNglnEyxylvNgqAep3o3q_QlrnwzTsA7lwhDZgMDDeH14lhWaAHiiLFVuaIh3ASm-axkPj2ucR-70SInhI74vWNIeD76JAdtGGaqke4e2Xl9-11uGZ_RM7CevJhsGJzCtCXKmDIoY-tS8IYIlrx9_WN0Kh8vDVFN45Bqko6TUom988hqqKx8QgUjwV-VR1yr0qr9boaEpxjTM7hvqfNrpbCpisrg0aW4J_WG-qK9w_qYVibZfcPNaBToQZnvNO1xumOUKRIO0Z3gBHLiKLvt5kMxXRxMhCq5DXHB2lUq9ejJtIDd4r-h-g2N3KtckYl8-8H_b5VeG3LK8aBjvAh_POu7WHFvVoZ23QnA9nfQEYHoDrXl05lSTfT9E88kCwOUZN9W3u2QwpNFzXNxeXSYD54ir2hTNiJo5N7xdyCnIEjHahfP5G9xsHU-4Uk9W8KcljCoA3XQvQ-pET8a-6HEtiAFs6Hnbbkm6jtdaQ1KQY=w975-h732-no

17' Stitch & Glue Canoe FZvZTB3nsFGXOq8NMuRjua_ohLALhw5cg7XRniT1r5sl44QmaMr4QsuMyMK1fdFnW2Oehk85ayLpxTtzhelJwYFHy9e-90Div8BbOBOJxutPm8MScP7m238wDgq23-smxmCYgy7t-BpIm1-BQGTPGJJ8WKTL4JJeJOVQ-dME2rFxJIBgpGQamrru_zP05TlB68QIPb9gVHetxdRaAUHsBC9gNM5h_iNYzcLU0fV3YQGsgBTF8jWt8ZYNff2odNxFtAi__a3u5-NJeBDZmYln8IpGsdV7ZSa5KEBA8bQftVCIoy1CMYNuCK6zhSFPgIVceB-duqk7kGyfKCjm5pAg-ikFbfUyAO6ozBX0d7mlteymwwNZMjdg9yHWgIbq11McvcE2dvLLnpmNP5DPHBMDbkugOdtDjqW155S4LrsboV3XiKDSlVE0lQEVCWh3UMsZL3vn8e2idHXupwUmZyaxv4n-sBK2gFzNOaf_CRj3c0VNNa6DIWr5U17zuTrhZSVdg1YT8hMqQi7iq8KLiWGGgbxLtQxxfPDekD8_RugfDu4=w549-h732-no

17' Stitch & Glue Canoe RuyIx_XCwVNMCbIldksd9vcEsH52Ldz-FVd0v5Og34IN3TIEuaGJgU0lfSHEidtFOCceUq6MNfrnYboabtNIhDzpZqhfCTgbXh-h-gZztYItlyw6jgt-H2tLokbwGvo_GO2CMS6SVNWRq7AWnu0BUMsV3j2d1-MknY2Nw8TN3b6-MLjIUQFgkUbqDIZnSSrvMZPEQOnzfJoSwk2rWIEcw-ba_G70-2vhPjDJMKo8NeysvDEBOvbihcvZ7OAhxegDTZp1EaSeuJGadqPKvEsegXyY-tLfIEwZ1_zfETRHRRkmb6ISYMa6IIoKUuMD0YAUYHiN6sN-wIEa2yF0PwGn04di4h2-bR5VLwhDJo7kpzXpqoWLrPuGe-Qfm7WDky73NMLFe8vDqPru5sMe6qlpRO9PJH1ycixGzKA7-ovE4QMSzjbRLgZ-eUQtPzcU7MhiLsgb1ToBBLkgfos6iex40VIrbS0jVvNZVgKkQcK8jWHa_13iBGNua53o_EQZDo-AidbMKaztucnWrMO13cGlc8KVD7F4lJRL9Qt7hsmrqUU=w975-h732-no

17' Stitch & Glue Canoe YPgsu-kNUik6t7jAThenzLR1NOj7ysUeTjBuBE3UfOQhYPBwXnprGzNhhgYOW7z2xjkrks37eXtqdsouCErF4bQ0GHct5nN7hURTYRWNEVFmd68Q-Z2Fm7TgUCzzSkBdnFSu6WxNRPBVw0VeCVVW_68oCb5990Kg890PSnKnYiongxnKe6NwKDLl6vvhiEEB2HEi9JtFYCfeN5kYR60O-Lxd55z7_4kpq9MmlYMPiIFFsFF7mPWib4oxQsqW_I7ZJH9nJAZfN43GSNw4z6M94vu3-dY3ZHvLfggvQPurD-WNKeiox-gh4_6SR1i8Pjv4CIfXRKzXEIxVfnIS_YLRepBSbatEWsAcOY5GgJZu9p_ylND2zBRjzyTSE8RhvxaBVNZE6k4hIgxEg9AtZnTiqbAqB6S9BDjr4RlwIdp1bo7Rj3VhT2v_JnxAZHBW8hRzwNFw6avDi6TM3QplmKIGUhrVaiJP8L9C05zmnsxWGwE7jwXJUrvHq23flASJ4s5Fkhherwnt2V6Yb_lFJmaKAHVvPz56QOXAd_QbfbZu9pM=w975-h732-no

Admin - Shine
Admin - Shine
Admin

Posts : 488
Join date : 2015-03-31

View user profile http://gulfstreamcomposites.forumotion.com

Back to top Go down

17' Stitch & Glue Canoe Empty Re: 17' Stitch & Glue Canoe

Post by Wej on Thu Aug 18, 2016 11:42 pm

Any new reports?
